Discover the enhanced R-VWP Rotary Lobe Vacuum Pump, now upgraded with an energy-efficient IE3 motor. Our state-of-the-art pump offers unparalleled performance with capacities ranging from 500 to 2000 m³/hr, making it the perfect solution for diverse industrial applications. Designed to handle the rigors of producing both coarse and fine vacuum, the R-VWP series stands out for its ability to manage gases and vapors, including water vapor and most corrosive gases. The latest model maintains its reputation for robustness while introducing advanced features that elevate its operational excellence.
Eco-Friendly Efficiency: Equipped with an IE3 motor, the R-VWP series delivers superior energy savings and reduced environmental impact.
Enhanced Capacity: With a broader range from 500 to 2000 m³/hr, the pumps cater to a wider array of industrial vacuum needs.
Versatility in Applications: Ideal for generating coarse and fine vacuums, these pumps are also adept at handling gases and vapors, ensuring reliable performance across various sectors.
Robust Construction: The dry running design means there's no need for grease or oil in the compression chamber, minimizing contamination risks.
Maintenance Ease: Oil-lubricated gearbox and bearings are separated from the compression chamber, simplifying maintenance and extending pump life.
Safety and Compliance: Flange mounted motors not only align with DIN EN 60034 but also boast IP 55 protection and insulation class F, ensuring operational safety and adherence to high standards.
Technical Features
R-VWP Technical Features
Models & Capacity: The R-VWP series includes models 501, 1001, and 2001, with respective nominal suction capacities of 500, 1000, and 2000 m³/hr at 50 Hz.
Pressure Adaptability: An integrated bypass valve allows for safe and efficient startup in tandem with backing pumps, handling a pressure difference at the overflow valve of 60 mbar across all models.
Sound Engineering: The pumps operate with an average noise level of 73-74 dB(A) according to EN ISO 3744, maintaining a quiet working environment.
Weight & Oil Capacity: The models vary in weight from 141 to 360 kg without the motor, and oil capacities range from 1.1 to 3.05 liters, facilitating customization and scalability.
Motor Specifications: Motors are available in 1.5kW, 3.0kW, and 5.5kW versions for 50 Hz, all featuring IP 55 protection and designed to perform optimally at their respective speeds.
